Theben
  • 1-way wireless flush-mounted switch actuator LUXORliving
  • Encrypted wireless communication
  • Adjustable features: NC/NO contact, switching, delayed switching, pulse function

View full description

Quick Find: 22227
Part Code: 4800620
Barcode: 4003468480212

Free Delivery Available
£68.59
£57.16 exc VAT

Selected Total: £0.00


    Qty

    Day of Choice Delivery available after checkout

    Need Help? Free Design Service

    Call 01473 559079 or email us for a bespoke design service for your underfloor heating project – FREE

    1-way wireless flush-mounted switch actuator LUXORliving

    Encrypted wireless communication

    Adjustable features: NC/NO contact, switching, delayed switching, pulse function

    2 binary inputs for floating contacts such as buttons, switches, temperature sensor (I2)

    The binary inputs are assigned to the switch output as standard (function test before programming)

    Integrated temperature monitoring for increased operating safety, e.g. in the event of overload

    Technical specifications

    Ambient temperature-5°C ... 45°C
    BrandTheben
    Frequency50 – 60 Hz
    Incandescent/halogen lamp load1800W
    Installation typein flush-mounted socket
    LED lamp < 2 W50W
    LED lamp > 8 W600W
    LED lamp 2-8 W600W
    Number of channels1
    Operating Voltage230 – 240 V AC 50 – 60 Hz
