- LUXORliving heating actuator for controlling thermal actuators
- Option of channel-based actuator control: 24 V DC switching or 0–10 V DC continuous
- Integrated relay for demand-based control of heating circuit pump
- No room thermostat required: each channel has a temperature control
- Can be installed directly in the heating circuit distributor
- Screw-less terminal technology
- Integrated power supply for max. 12 thermal actuators
- Continuous or switching actuating value can be selected
- Integrated valve protection - Manual operation on device
Technical specifications
| Ambient temperature | -5°C ... 50°C |
|---|---|
| Brand | Theben |
| Frequency | 50 – 60 Hz |
| IP Rating | IP20 |
| Operating Voltage | 230 – 240 V AC 50 – 60 Hz |
| Protection rating | II according to EN 60 669 |
| Stand-by consumption | <1 W |
| Switching output | 5 A, 240 V AC potenzialfrei (Pumpe) |
