Danfoss WT-T - BasicPlus2 - Manual Room -Thermostat

More from BasicPlus2

Danfoss WT-T - BasicPlus2 - Manual Room -Thermostat
Danfoss WT-T - BasicPlus2 - Manual Room -Thermostat
Danfoss
  • Modern design
  • Simple manual operation
  • Frost protection mode
  • Display indication lights

View full description

Quick Find: 18286
Part Code: 088U0620
Barcode: 5702425102974
Weight: 0.17 Kg

Free Delivery Available
£18.23
£15.19 exc VAT
RRP: £24.30
Stock Available: 37 Units

Selected Total: £0.00


    Qty

    Day of Choice Delivery available after checkout

    Need Help? Free Design Service

    Call 01473 559079 or email us for a bespoke design service for your underfloor heating project – FREE

    Room thermostat, WT-T (Dial)

    230V hardwired room thermostats for hydronic floor heating or other applications with thermal actuators.

    By turning the dial to the desired set-point temperature, optimal thermal comfort in the room is achieved.

    In addition to temperature, the thermostat setting scale includes a frost symbol allowing for minimal energy consumption while avoiding freezing temperatures in the room.

    The thermostat is equipped with diodes, which display a green light through the front cover while the thermostat is on, but without heat demand. A red light is displayed when the thermostat is on and there is heat demand.

    Customers who bought this also bought

    Technical specifications

    BrandDanfoss
    ColourWhite RAL9010/Dark Grey RAL7024
    Dimensions86 x 86 x 16 mm
    Erp ratingClass 1
    Floor temperature rangeOff, 20 - 45° C
    Installation typeOn-wall
    IP RatingIP30
    Operating temperature rangeOff, 5 - 35° C
    SensorNTC 100K, accuracy: ±1%
    TypeLCD display with push buttons
    Voltage230V 50/60Hz V

    Product downloads

    Data Sheet

    File Size: 1.19 MB

    Installation Guide

    File Size: 592.09 KB
